Overview
2x4, 192 kHz, USB-C® Compatible Audio Interface
Created with the needs of DJs and electronic musicians in mind, the Studio 26c delivers excellent audio quality with professional metering and flexible monitoring options. With two of PreSonus®' pristine XMAX-L mic preamps for recording vocals, high-headroom instrument preamps to connect your guitar or bass directly to your interface, and professional input metering so you can keep track of your recording levels, the Studio 26c delivers amazing sound quality in a rugged, compact form factor.
When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX-L mic preamps let you capture complex musical harmonics smoothly and naturally. Professional input and output metering let you keep an eye on your levels when you're recording by yourself. An easy-to-use direct monitor control blends the analog input signals with playback from your computer, simplifying monitoring. Route two different stereo mixes to dedicated outputs. Listen in to either mix on your headphones with a quick Cue A / B button toggle.
Whether you're just getting into music production or looking to upgrade your DJ rig, the Studio 26c will give you clear, clean, ultra-high-def sound in a bus-powered, rugged unit. A complete home recording studio right out of the box, the Studio 24c audio interface comes with 6-months of Studio One Pro+ so you can start recording right away.
Overview
Features
- 2 pristine XMAX-L solid-state mic preamps to capture every detail
- 2 high-headroom instrument/line inputs to record guitar, bass, and your favorite synths
- Cue Mix A/B function that toggles between two mixes while monitoring through headphones - perfect for DJs and electronic musicians
- Studio-grade converters for 24-bit/192 kHz recording and playback
- Professional input and output metering to keep an eye on your recording levels
- MIDI I/O for external production tools
- 2 balanced ¼" TRS line outputs for monitor mixing
- 2 balanced ¼" TRS main outputs with front-panel level control
- 4 ladder-style LED level meters (2 input, 2 main output)
- USB-C to USB-C and USB-C to USB-A cables included
- 6-months of Studio One Pro+ and Studio Magic Plug-in Suite included
Downloads
Don't see what you're looking for?
Log in to your my.presonus.com account.
Support
Resources
Don't see what you're looking for?
Log in to your my.presonus.com account.
Highlights
Studio One Pro 7 DAW Software Access Included.
Your hardware registration includes a 6-month stackable membership to Studio One Pro+ featuring unlimited access to the latest version of Studio One Pro and all the extras.
Specs
Electronics
Connectivity
USB-C® Compatible USB 2.0 Connection
Headphone Jack
1/4" TRS Active Stereo
Inputs
Two - Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4" TS Female Unbalanced (Inst) or TRS Female Balance (Line))
Line Out
Two - 1/4" Balanced (Left and Right)
Phantom Power
+48 VDC, 10 mA
Voltage
USB Bus Powered
General
Color
Black and Blue
Product Name
Studio 26c, Black and Blue
Series
Studio
Inputs
Instrument Inputs Dynamic Range
110 dB (A-Weighted, Minimum Gain)
Instrument Inputs Frequency Response
20 Hz - 20 kHz (± 0.15 dB, Minimum Gain, 48 kHz)
Instrument Inputs Gain Range
70 dB
Instrument Inputs Maximum Level
+14 dBu (Unbalanced, Minimum Gain)
Line Inputs Dynamic Range
110 dB (A-Weighted, Minimum Gain)
Line Inputs Frequency Response
20 Hz - 20 kHz (± 0.1 dB, Minimum Gain, 48 kHz)
Line Inputs Gain Range
70 dB
Line Inputs Impedance
10 kΩ
Line Inputs Maximum Level
+19.5 dBu (balanced, Minimum Gain)
Line Inputs Total Harmonic Distortion
THD+N 0.007% (1 kHz, -1 dBFS, Minimum Gain)
Microphone Preamp Dynamic Range
110 dB (A-Weighted, Minimum Gain)
Microphone Preamp Equivalent Input Noise
-125 dBu (Maximum Gain, 150Ω, A-Weighted)
Microphone Preamp Frequency Response
20 Hz - 20 kHz (± 0.1 dB, Minimum Gain, 48 kHz)
Microphone Preamp Gain Control Range
70 dB
Microphone Preamp Input Impedance
1.6 kΩ
Microphone Preamp Maximum Input Level
+4.5 dBu (balanced, Minimum Gain)
Microphone Preamp Total Harmonic Distortion
THD+N 0.004% (1 kHz, -1 dBFS, Unity Gain)
Measurements
Product Depth
5.5" (139.7 mm)
Product Height
1.75" (44.45 mm)
Product Width
7" (17.8 cm)
Miscellaneous
Commodity Code
8517620000
Power Cable
USB-C® Bus-Powered
Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, or 192
Output
Headphone Outputs Dynamic Range
104 dB (A-Weighted, 56Ω Load)
Headphone Outputs Frequency Response
20 Hz to 20 kHz (±0.2 dB, 56Ω Load, 48 kHz)
Headphone Outputs Impedance Working Range
32Ω to 300Ω
Headphone Outputs Maximum Output
30 mW / Channel (56Ω Load)
Headphone Outputs Total Harmonic Distortion
THD+N 0.009% (1 kHz, -1 dBFS, no Load)
Main And Line Outputs Dynamic Range
108 dB (A-Weighted) (Line Outs 1 and 2), 104 dB (A-Weighted, 56Ω Load)
Main And Line Outputs Frequency Response
20 Hz - 20 kHz (± 0.1dB, Unity Gain, 48 kHz)
Main And Line Outputs Maximum Level
+10 dBu (balanced)
Main And Line Outputs Total Harmonic Distortion
THD+N 0.0015% (1 kHz, -1 dBFS)
Performance
Digital Audio Bit Depth
24 bit
Digital Audio Dynamic Range
114 dB
