Studio 24c
Studio 24c
SKU: 2777700403
Regular price
$236.00
Regular price
$236.00
Sale price
$236.00
Unit price
per
Our rugged 2x2, 24-bit / 192 kHz, USB-C recording audio interface with Studio One Pro recording software access included.
Couldn't load pickup availability
Studio 24c
Regular price
$236.00
Regular price
$236.00
Sale price
$236.00
Unit price
per
Overview
Whether you're recording your first album or your hit podcast's latest episode, the Studio 24c will help you sound your best. With two of PreSonus®' pristine XMAX-L mic preamps for recording vocals, high-headroom instrument preamps so you can connect your guitar or bass directly to your interface, and professional input metering so you can keep track of your recording levels, the Studio 24c delivers amazing sound quality in a rugged, compact form factor.
When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX-L mic preamps let you capture complex musical harmonics smoothly and naturally. Professional input and output metering let you keep an eye on your levels when you're recording by yourself. An easy to use Mix control lets you blend your analog inputs with playback from your computer, making creating a great monitor mix fast and simple.
Whether you're just getting into recording or are a veteran producer who wants to go mobile, the Studio 24c will give you clear, clean, ultra-high-def sound in a bus-powered, rugged unit. A complete home recording studio right out of the box, the Studio 24c audio interface comes with 6-months of Studio One Pro+ so you can start recording right away.
Overview
Features
- Simultaneous I/O up to 2 inputs/2 outputs
- 2 mic/instrument/line inputs with XMAX-L mic preamps
- 2 balanced ¼-inch TRS main outputs to connect professional studio monitors
- High-power headphone output
- MIDI In/Out
- Mixer knob for low-latency direct input monitoring
- Front-panel level controls for main outputs
- 4 ladder-style LED level meters (2 input, 2 main output)
- 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
- Includes 6-months of Studio One Pro+ and the Studio Magic Software Suite
Downloads
Don't see what you're looking for?
Log in to your my.presonus.com account.
Support
Resources
Don't see what you're looking for?
Log in to your my.presonus.com account.
Highlights
Studio One Pro 7 DAW Software Access Included.
Your hardware registration includes a 6-month stackable membership to Studio One Pro+ featuring unlimited access to the latest version of Studio One Pro and all the extras.
Specs
Electronics
Connectivity
USB-C®
Headphone Jack
1/4" Stereo
Inputs
Two - Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4" TS Female Unbalanced (Inst) or TRS Female Balance (Line))
Line Out
Two - 1/4" Balanced (Left and Right)
Phantom Power
+48 VDC, 10 mA
Voltage
USB Bus Powered
General
Color
Black and Blue
Product Name
Studio 24c, Black and Blue
Series
Studio
Inputs
Instrument Inputs Dynamic Range
105 dB (A-Weighted, Unity Gain)
Instrument Inputs Frequency Response
20 Hz – 20 kHz (±0.1 dBu, Unity Gain, Unweighted)
Instrument Inputs Gain Range
50 dB
Instrument Inputs Maximum Level
+19 dBu (Minimum Gain)
Microphone Input Connection Type
Combo Locking XLR Mic - 1/4” TRS Line
Microphone Preamp Dynamic Range
106 dB (A-Weighted, Minimum Gain)
Microphone Preamp Equivalent Input Noise
-126 dBu (A-Weighted, 150Ω, Maximum Gain)
Microphone Preamp Frequency Response
20 Hz - 20 kHz (±0.3 dBu, Unity Gain, Unweighted)
Microphone Preamp Gain Control Range
50 dB
Microphone Preamp Input Impedance
1.4 kΩ
Microphone Preamp Maximum Input Level
+10 dBu (±0.5 dBu, Minimum Gain)
Microphone Preamp Total Harmonic Distortion
0.004% (1 kHz, -1 dBFS, Minimum Gain)
Measurements
Product Depth
5.5" (139.7 mm)
Product Height
1.75" (44.45 mm)
Product Width
7" (17.8 cm)
Miscellaneous
Commodity Code
8517620000
Power Cable
USB-C Cable
Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, or 192 kHz (kHz)
Output
Headphone Outputs Dynamic Range
83 dB (A-Weighted, 56Ω Load)
Headphone Outputs Frequency Response
20 Hz – 20 kHz (±0.5 dBu, Unity Gain, Unweighted)
Headphone Outputs Impedance Working Range
32Ω to 300Ω
Headphone Outputs Maximum Output
47 mW/Channel @56Ω
Headphone Outputs Total Harmonic Distortion
0.01% (1 kHz, 0 dBFS, Loaded)
Line Outputs Connection Type
1/4" TRS, Balanced
Main And Line Outputs Dynamic Range
104 dB (Unity Gain, Unweighted)
Main And Line Outputs Frequency Response
20 Hz - 20 kHz (±0.3 dBu, Unity Gain, Unweighted)
Main And Line Outputs Maximum Level
+10 dBu (1 kHz, Unity Gain, Balanced)
Main And Line Outputs Total Harmonic Distortion
0.001% (1 kHz, -1 dBFS, Unity Gain)
Main Outputs Connection Type
1/4" TRS, Balanced
Performance
Digital Audio Bit Depth
24 Bit
Digital Audio Dynamic Range
108 dB
