Overview
PreSonus® was a pioneer in high-channel-count audio interfaces and has spent the last 20 years creating the best audio interfaces for recording large sessions. Building on this legacy, the Studio 1824c provides amazing sound-quality with eight of PreSonus' lauded XMAX analog mic preamps onboard and pristine 24-bit 192 kHz conversion. Add two low-noise instrument preamps, balanced line-level inputs, and an ADAT input to add 8 more channels whenever you need them, and you have an audio interface ready to record just about any session.
When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX mic preamps capture complex musical harmonics smoothly and naturally, with no audible distortion. XMAX mic preamps deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound, so you'll hear every breath, transient, and detail in your recordings. Professional input and output metering let you keep an eye on your levels. A flexible DSP mixer lets you create four discrete near-zero-latency monitor mixes. Front-panel Mute, Mono, and level controls let you work with your main mix.
Whether you're upgrading your studio or building a new space for your band to record, the Studio 1824c has you covered with superior mic preamps, expandable inputs, and powerful, easy-to-use onboard monitor mixing to give you the world-class results you want.
Overview
Features
- Up to 18 inputs/20 outputs simultaneously (8x8 at 192 kHz)
- 2 mic/instrument/line inputs with XMAX Class A mic preamps
- 6 mic/line inputs with XMAX Class A mic preamps
- 8 channels of ADAT Optical I/O (4 channels at 96 kHz)
- 2 balanced ¼-inch TRS main outputs and 8 balanced ¼-inch TRS line outputs for monitor mixing, all DC coupled for sending control voltages
- 2 stereo headphone outputs with individual level controls
- Stereo S/PDIF digital I/O and MIDI In/Out
- 18x8 onboard DSP monitor mixer
- Front-panel level controls plus Mono and Mute buttons for the main outputs
- True 48V phantom power for condenser microphones (global)
- 10 ladder-style 8-LED level meters (8 input, 2 main output)
- 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
- Professional Recording Software Included - Fender Studio Pro License
Downloads
Don't see what you're looking for?
Log in to your my.presonus.com account.
Documentation
Software
- Universal Control v5.0 Download (Windows)
- Universal Control v5.0 Download (Mac)
- Universal Control v5.0 (Android)
- Universal Control v4.7.2.108537 Download (Mac)
- Universal Control v4.7.2.108537 Download (Windows)
- Universal Control v4.7.2.108537 (Android)
- Universal Control v4.7.1.107907 Download (Mac)
- Need an older version? Click here
Don't see what you're looking for?
Log in to your my.presonus.com account.
Highlights
Fender Studio Pro DAW Software Included.
Your hardware registration includes a perpetual License to Fender Studio Pro.
Specs
General
Product Name
Studio 1824c, Black, 120V
Series
Studio
Color
Black
Microphone Inputs
Connection Type
XLR Female (Combo), Balanced
Frequency Response
20 Hz - 20 kHz (Unity Gain)
Input Impedance
1.4 kΩ
Dynamic Range
110 dB (A-Weighted, Minimum Gain)
EIN
-128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)
THD+N
0.005% (1 kHz, 0dBu, Unity Gain)
Gain Range
80 dB
Maximum Input Level
+16 dBu, Minimum Gain
Phantom Power
+48 VDC
Line Inputs
Frequency Response
20 Hz - 20 kHz (Unity Gain)
Input Impedance
10 kΩ
Dynamic Range
112 dB (A-Weighted, Minimum Gain)
THD+N
0.005% (1 kHz, +18 dBu, Minimum Gain)
Gain Range
40 dB
Maximum Input Level
+21 dBu (Balanced, Minimum Gain)
Instrument Inputs
Frequency Response
20 Hz - 20 kHz (Minimum Gain)
Dynamic Range
112 dB (A-Weighted, Minimum Gain)
THD+N
0.020% (1 kHz, +10 dBu, Minimum Gain)
Gain Range
80 dB
Maximum Input Level
+15 dBu (Unbalanced, Minimum Gain)
Line Outputs
Connection Type
1/4" TRS Female
Main Outputs
Connection Type
1/4" TRS Female
Headphone Outputs
Connection Type
1/4" TRS Active Stereo
Frequency Response
20 Hz - 20 kHz (Unity Gain)
Impedance Working Range
32Ω to 600Ω
Dynamic Range
103 dB (A-weighted, 1 kHz, Unity Gain)
THD+N
0.250% (1 kHz, 150 mW, Unity Gain)
Maximum Output Level
150 mW/Channel (60Ω Load)
MIDI I/O
Connection Type
Dual 5-Pin Female DIN
Power
Voltage
120V
Voltage Requirements
100-240 VAC, 50-60 Hz
Digital Audio
Connectivity
USB-C®
Bit Depth
24 Bit
Dynamic Range
114 dB
Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)
Measurements
Height
1.75" (44.45 mm)
Depth
5.5" (140 mm)
Width
19" (483mm)
Weight
4.8 lbs. (2.2 kg)
