Studio 1810c
Studio 1810c
Couldn't load pickup availability
Overview
You don't need to sacrifice mobility for connectivity. Take amazing studio-quality sound and flexible input options on the road with the PreSonus® Studio 1810c audio interface. With four of PreSonus' lauded XMAX analog mic preamps, high-quality instrument preamps, balanced line-level inputs, and an ADAT input to add eight more channels whenever you need them, the Studio 1810c is a compact recording powerhouse housed in a rugged, roadworthy chassis.
When you have the right tools, any job is easier and faster to finish. High-quality converters and PreSonus' professional-grade XMAX mic preamps enable you to capture complex musical harmonics smoothly and naturally, with no audible distortion. XMAX mic preamps deliver incredibly high headroom, deep lows, smooth highs, and a rich overall sound, so you'll hear every breath, transient, and detail in your recordings. Professional input and output metering let you keep an eye on your levels when you're recording by yourself. Easy-to-use DSP monitor mixing lets you create four discrete mixes for you and three others. Two pairs of outputs afford two different stereo mixes. The Cue A/B button allows you to toggle between each mix while listening in on headphones, great for dialing in monitor mixes from the control room.
When you need to be ready to create professional recordings anywhere, the Studio 1810c has you covered with superior mic preamps and expandable inputs to give you world-class results.
Overview
Features
- Simultaneous I/O up to 18 inputs/8 outputs (8x6 at 192 kHz)
- 2 mic/instrument/line inputs with XMAX Class A mic preamps
- 2 mic/line inputs with XMAX Class A mic preamps
- 4 balanced ¼-inch TRS direct-to-ADC line inputs
- 8 channels of ADAT Optical input (4 channels at 96 kHz)
- 2 balanced ¼-inch TRS main outputs and 2 balanced ¼-inch TRS line outputs for monitor mixing all DC coupled for sending control voltages
- High-power headphone output
- Stereo S/PDIF digital I/O and MIDI In/Out
- 18x6 onboard DSP monitor mixer
- Front-panel mute and level controls for main outputs
- 6 ladder-style 8-LED level meters (4 input, 2 main output)
- 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
- Includes 6-months of Studio One Pro+ and Studio Magic Software Suite
Downloads
Don't see what you're looking for?
Log in to your my.presonus.com account.
Documentation
Software
Don't see what you're looking for?
Log in to your my.presonus.com account.
Highlights
Studio One Pro 7 DAW Software Access Included.
Your hardware registration includes a 6-month stackable membership to Studio One Pro+ featuring unlimited access to the latest version of Studio One Pro and all the extras.
Specs
Electronics
Connectivity
USB-C®
Headphone Jack
1/4" TRS Active Stereo
Inputs
Eight - Four Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4" TS Female Unbalanced (Inst), Four 1/4" Line
Phantom Power
+48 VDC
VoltageRequirements
100-240 VAC, 50-60 Hz
General
Color
Black
Product Name
Studio 1810c, Black, 120V
Series
Studio
Inputs
Instrument Inputs Dynamic Range
112 dB (A-Weighted, Minimum Gain)
Instrument Inputs Frequency Response
20 Hz - 20 kHz (Minimum Gain)
Instrument Inputs Gain Range
80 dB
Instrument Inputs Maximum Level
+15 dBu (Unbalanced, Minimum Gain)
Line Inputs Dynamic Range
112 dB (A-Weighted, Minimum Gain)
Line Inputs Frequency Response
20 Hz - 20 kHz (Unity Gain)
Line Inputs Gain Range
40 dB
Line Inputs Impedance
10 kΩ
Line Inputs Maximum Level
+21 dBu (balanced, Minimum Gain)
Line Inputs Total Harmonic Distortion
0.005% (1 kHz, +18 dBu, Minimum Gain)
Microphone Input Connection Type
Combo Locking XLR Mic - 1/4” TRS Line
Microphone Preamp Dynamic Range
110 dB (A-Weighted, Minimum Gain)
Microphone Preamp Equivalent Input Noise
-128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)
Microphone Preamp Frequency Response
20 Hz - 20 kHz (Unity Gain)
Microphone Preamp Gain Control Range
80 dB
Microphone Preamp Input Impedance
1.4 kΩ
Microphone Preamp Maximum Input Level
+16 dBu, Minimum Gain
Microphone Preamp Total Harmonic Distortion
0.005% (1 kHz, 0dBu, Unity Gain)
Measurements
Product Depth
5.5" (140 mm)
Product Height
1.75" (44.45 mm)
Product Width
12.5" (317.5 mm)
Miscellaneous
Supported Sample Rates
44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)
Output
Headphone Outputs Dynamic Range
103 dB (A-weighted, 1 kHz, Unity Gain)
Headphone Outputs Frequency Response
20 Hz - 20 kHz (Unity Gain)
Headphone Outputs Impedance Working Range
32Ω to 600Ω
Headphone Outputs Maximum Output
150 mW/Channel (60Ω Load)
Headphone Outputs Total Harmonic Distortion
0.250% (1 kHz, 150 mW, Unity Gain)
Line Outputs Connection Type
1/4" TRS, Balanced
Main And Line Outputs Dynamic Range
108 dB (A-Weighted, Unity Gain)
Main And Line Outputs Frequency Response
20 Hz - 20 kHz (Unity Gain)
Main And Line Outputs Maximum Level
+18 dBu, Balanced
Main And Line Outputs Total Harmonic Distortion
0.004% (1 kHz, -1 dBFS, Unity Gain)
Main Outputs Connection Type
1/4" TRS, Balanced
