FireStudio

FireStudio

SKU: FIRESTUDIO

View full details

FireStudio

      Overview

      The PreSonus FireStudio is the next generation in FireWire recording systems from PreSonus. Based on the award-winning Firepod, the FireStudio combines superior analog circuit design with new advanced platform technology to deliver enhanced performance for music recording and creation.

      The FireStudio is a 26x26 24-bit/96k professional recording system combining eight XMAX Class A PreSonus microphone preamplifiers, up to sixteen channels of optical ADAT input / output, S/PDIF and MIDI input / output, along with the Control Console - a 36x36x18 zero latency mixer/router.

      The FireStudio is bundled with PreSonus Studio One Artist, our groundbreaking music creation program, and over 4 GB of virtual instruments, plug-ins, loops, and samples to get you started making music immediately.

      Overview

      Features

      • 8 dual-purpose front-panel channel inputs, each with high-headroom Class A XMAX™ mic preamplifiers
        • 6 mic/line inputs
        • 2 mic/instrument inputs
        • Individual channel-trim controls with -20 to +20 dBV line / 0 to 60 dBu mic range and clip LED
        • 48V phantom power for condenser microphones (Inputs 1-4 and 5-8, bank-switchable)
      • Headphone jack with level control
      • Main-output gain control
      • Power/Sync LED (indicates unit is synced to word clock)
      • Daisy-chain multiple FireStudios or other FireStudio-family products to create a large, custom system
      • Remote controllable via optional Monitor Station Remote (MSR)
      • Studio One Artist™ digital audio workstation software included
      • 2 FireWire 400 ports
      • S/PDIF digital input/output
      • 16 channels of optical ADAT I/O @ 44.1/48 kHz (8 ch. @ 96 kHz via dual SMUX)
      • 6 combination XLR/¼” mic/line-level inputs
      • 2 combination XLR/¼” mic/instrument (high impedance) inputs
      • Unbalanced stereo line-level inputs (RCA)
      • 2 stereo ¼” inserts
      • 2 ¼” main (L/R) analog outputs
      • 8 ¼” general-purpose outputs
      • MIDI in/out
      • Word-clock in/out (BNC)
      • Remote-control input
      • ¼” headphone output
      • 24-bit resolution, up to 96 kHz sampling rate
      • High-definition analog-to-digital converters (118 dB dynamic range)
      • DICE II chipset for ultra-efficient data transfer
      • JetPLL™ jitter-elimination technology
      • Zero-latency monitoring via 36x18 DSP matrix mixer/router
      • Mac®- and Windows®-compatible, including Mac OS X 10.6 Snow Leopard and Windows 7
      • Supports ASIO, Core Audio, Direct Sound (Windows XP), Windows Audio Session API (Windows Vista and Windows 7)
      • 1U 19” rack-mountable, rugged steel chassis
      • Sealed, detented, metal rotary controls
      • Internal power supply with standard IEC power cord
      • Studio One® Artist
        • PreSonus’ revolutionary new digital audio workstation, with unlimited track count and 6+ GB of 3rd-party resources. With Studio One's Nimbit® extension, you can immediately start selling your music.
      • Universal Control control-panel application for Mac® OS X and Windows®

      Downloads

      Support

    • Universal Control Software Reference Manual - English
    • Wiring the FireStudio for All MSR Modes - English
    • FireStudio with MSR Hookup Diagram for Full Band Monitoring - English
    • Owner's Manual for Monitor Station Remote - English
    • Owner's Manual for Monitor Station Remote - French
    • Owner's Manual - English
    • Owner's Manual for Monitor Station Remote - Portuguese
    • 2-Year Limited Non-Transferable Warranty (Multilingual)
    • Owner's Manual - Portuguese
    • Owner's Manual - French

      • Resources

    • FireControl 2626 (Mac)
    • Universal Control v1.2.2715, Driver v3.5.5 (Windows)
    • Universal Control v1.2.2715, Driver v3.5.5 (Mac)
