AIR10 2-Way Active Sound-Reinforcement Loudspeaker

AIR10 2-Way Active Sound-Reinforcement Loudspeaker

$516.00
$516.00 $516.00
Sale Sold out
Our compact and lightweight 2-way active sound-reinforcement loudspeakers for extended low-end and high-frequency extension.
View full details

AIR10 2-Way Active Sound-Reinforcement Loudspeaker

$516.00
$516.00 $516.00
Sale Sold out

      Overview

      Compact and lightweight, the PreSonus® AIR10 2-way active PA loudspeaker's 10-inch woofer and 1-inch HF driver deliver a rich, extended low-end and natural high-frequency extension in an enclosure that fits in the back of a small car. Backed by 1,200W (peak) of Class D/Class AB power and enhanced with easy-to-use digital tuning functions, the AIR10 gives you all the power and tools you need for both mobile and installed sound. A choice of inputs enables use with a variety of sources.

      An easy-to-use signal processor with presets makes it simple to customize the AIR10's response for use as front-of-house mains, as monitor wedges, for music playback, for improved speech intelligibility and for enhanced low end and a warmer sound. Treble and bass controls boost or cut by 10 dB to compensate for room anomalies. Location presets optimize performance for stand and bracket mounting as well as flown installations.

      The AIR10's multi-angle enclosure sports nonskid rubber feet on the bottom for upright front-of-house use and on one side for stage monitor applications. Rig it using M10 fly points or ground-stack for portable applications. Mount it on a tripod or atop an AIR-series subwoofer using an optional sub pole. An integrated dual-position pole mount lets you aim the speaker level or at a 7.5˚ downward tilt. And the AIR10 is easy to transport, thanks to its top-mounted handle.

      With its pro features and audio quality, the AIR10 is a great choice for mobile and installed sound.

      Overview

      Features

      • 1-inch, high-frequency compression driver and 10-inch woofer with a 2-inch voice coil
      • 900W (peak) Class D power amplifier for LF driver and 300W (peak) Class A/B amplifier for HF driver
      • Maximum SPL 121 dB peak with 66 Hz to 20 kHz frequency response
      • 90° x 60° (horizontal x vertical) dispersion pattern
      • Onboard mixer with two combo XLR and ¼-inch inputs and one summed balanced output
      • Easy-to-use DSP performance presets: DJ (music playback), FOH (normal front-of-house), Monitor (floor wedge), Speech (intelligibility)
      • Additional presets and controls: Stand (pole or tripod mounting), Bracket (wall mounting), Suspend (flown applications)
      • Rugged, plastic, multi-angle enclosure for mains or monitor-wedge applications, with comfortable ergonomic handle and tour-grade, 1.2 mm steel grille
      • 35 mm pole socket with 7.5˚ downward tilt
      • M10 rigging points for suspended installation
      Video - click to play video

      Downloads

      • Owner's Manual - AIR Series (English)
      • 6-Year Limited Transferable Warranty (Multilingual)
      • Dimensions Sheet

      Highlights

      AIR10 2-Way Active Sound-Reinforcement Loudspeaker Multiple Inputs for a Variety of Sources

      Multiple Inputs for a Variety of Sources

      AIR full-range loudspeakers feature two combo XLR mic/TRS line inputs, each with a Class A mic preamp and independent gain control. A stereo ⅛-inch connection admits signals from consumer audio devices. These signals can be combined with the internal mixer, and a balanced XLR Mix output lets you pass the signals to other AIR-series loudspeakers.

      AIR10 2-Way Active Sound-Reinforcement Loudspeaker PreSonus® AIR Series Six-Year Warranty

      PreSonus® AIR Series Six-Year Warranty

      When you choose AIR-series loudspeakers, you choose confidence. Rest assured that your PreSonus® speakers are in it for the long haul. We take our build quality seriously, and if anything goes wrong with them in your first six years of ownership (assuming you don’t abuse them), the repair or replacement is on us.

      Specs

      Auxiliary Input

      1/8 in (3.5 mm) Stereo

      Channels

      Three

      Inputs

      Three - (2 x XLR/TRS Mic/Line Combo, 1 x 1/8” TRS Stereo)

      Line Out

      One - 1 x XLR Mix Out

      Power Consumption

      2.3A (230V-50 Hz), 4.6A (120V)

      VoltageRequirements

      100-240 VAC, 50-60 Hz

      Amplifier Type

      Class D (LF), Class AB (HF)

      Color

      Black

      Product Name

      AIR10 2-Way Active Sound-Reinforcement Loudspeaker, Black

      Series

      AIR

      Cabinet Material

      H-PP Molded

      Grille Material

      1.2 mm Steel

      HF Powere

      300 Watts

      HF Transducers

      1” Compression

      Handle

      1 Top

      LF Power

      900 Watts

      LF Transducers

      10” (2” Voice Coil)

      Pole Socket

      Dual Position (0˚, 7.5˚)

      Product Depth

      11.5" (291 mm)

      Product Height

      20.3" (516 mm)

      Product Width

      11.8" (300 mm)

      DSP Features

      LCD Screen With EQ And Multiple Presets

      Power Cable

      IEC

      Suspension

      M10 Suspension Points, Flypoints: 2 Top, 1 Back

      Peak SPL

      121 dB

      Total Power Output

      1200 Watts (Peak)

      Coverage Pattern

      90 degree (H) x 60 degree (V)

      Crossover Frequency

      2.2 kHz

      Speaker Type

      Active 2-Way

      Total Impedance

      NA
